| Model | GBP |
| 24-100R | 24-200R | 48-100R | 48-200R | 48-280R | 48-314R | 51.2-100R | 51.2-200R | 51.2-280R | 51.2-314R |
| Nominal
Voltage (V) | 25.6 | 48 | 51.2 |
| Cell
Specification | 100 | 100 | 100 | 100 | 280 | 314 | 100 | 100 | 280 | 314 |
| Nominal
Capacity (Ah) | 100 | 200 | 100 | 200 | 280 | 314 | 100 | 200 | 280 | 314 |
| Nominal
Energy (kWh) | 2.56 | 5.12 | 4.8 | 9.6 | 13.44 | 15.1 | 5.12 | 10.24 | 14.33 | 16.1 |
| Operating Voltage
Range (V) | 22.4~29.2 | 42~54.75 | 44.8~58.4 |
| Recommended
Charging
Voltage (V) | 27.6 | 51.75 | 55.2 |
| Recommended
Discharge
Cut-off Voltage (V) | 24 | 45 | 48 |
| Standard
Charge/Discharge Current (A) | 0.5C |
| Maximum
Continuous
Charge/Discharge
Current (A) | 1C (Customizable) |
| Operating
Temperature (C) | -30~60(Recommend 10~35) |
| Allowable
Humidity
Range(%RH) | <85 |
| Storage
Temperature(C) | -20~65(Recommend 10~35) |
| Charging Temperature(C) | 0~55 |
| Discharging
TemperatureC) | -10~55 |
| Protection Level | IP20 |
| Cooling Method | Natural Air Cooling /Intelligent Fan |
| Cycle Life | 5000+Times at 80% DOD |
| Maximum Dimension
(D*W*H)mm | 689*495*162 | 689*495*162 | 682*510*246 | 904*465*252 | 689*495*162 | 682*510*246 | 904*465*252 |
| Weight(kg) | 28 | 49 | 46 | 93 | 134 | 136 | 49 | 96 | 138 | 140 |
| Note:The maximum charge/discharge rate of models GBP48-200R and BP51.2-200R can be customized to 1C.
The above data is for reference only. In case of any changes, no further notice will be given. |
