| Model | GBP24-100W | GBP24-200W | GBP48-100W | GBP48-200W | GBP51.2-100W | GBP51.2-200W |
| Nominal
Voltage (V) | 25.6 | 48 | 51.2 |
| Cell
Specification | 100 | 100 | 100 | 100 | 100 | 100 |
| Nominal
Capacity (Ah) | 100 | 200 | 100 | 200 | 100 | 200 |
| Nominal
Energy (kWh) | 2.56 | 5.12 | 4.8 | 9.6 | 5.12 | 10.24 |
| Operating Voltage Range(V) | 22.4~29.2 | 42~54.75 | 44.8~58.4 |
| Recommended Charging Voltage (V) | 27.6 | 51.75 | 55.2 |
| Recommended Discharge
Cut-off Voltage (V) | 24 | 45 | 48 |
| Standard Charge/
Discharge Current (A) | 0.5C |
| Maximum Continuous
Charge/Discharge Current (A) | 1C (Customizable) |
| Operating
Temperature ("C) | -30~60(Recommended 10~35) |
| Allowable Humidity
Range(%RH) | <85 |
| Storage Temperature(°C) | -20~65(Recommended 10~35) |
| Charging Temperature (°C) | -10~55 |
| Discharging
Temperature("C) | -10~55 |
| Protection Level | IP20 |
| Cooling Method | Natural Air Cooling / Intelligent Fan |
| Cycle Life | 5000+ Times at 80% DOD |
| Maximum Dimension
(D*W*H)mm | 687*450*186 | 682*465*276 | 687*450*186 | 682*465*276 |
| Weight(kg) | 28 | 49 | 46 | 93 | 49 | 96 |
| Note: The above data is for reference only. in case of any changes, no further notice will be given.For customization requirements such as Bluetooth function and 1C charge/discharge rate, please consult with the engineer |
