Model	GBP-Pro-I Series
	24V100AH	24V200AH	48V100AH	48V200AH	48V314AH	51.2V100AH	51.2V200AH	51.2V314AH
Rated Voltage (V)	25.6		48			51.2
Rated Capacity (Ah)	100	200	100	200	314	100	200	314
Operating Voltage Range (V)	22.4~29.2		42~54.75			44.8~58.4
Recommended Charging Voltage (V)	27.6		51.75			55.2
Recommended Discharge Cut-off Voltage (V)	24		45			48
Standard Charge/ Discharge Current (A)	0.5C
Max Continuous Charge/ Discharge Current (A)	50/100	200	50/100	200	150	50/100	200	150
Allowable Humidity Range (%RH)	85
Storage Temperature (°C)	-20~55（Recommended:10~35）
Charging Temperature (°C)	0~55/-20~55（Heating function optional）
Protection Rating	IP20
Cooling Method	Natural Air Cooling
Cycle Life	≥6000
Communication Protocol	CAN/RS485
Capacity Expansion	Up to 20 modules in parallel (max. 48 modules for special applications)
Dimensions (D×W×H, mm)	635*375*156	635*375*156	635*375*156	660*400*245	972*480*245	635*375*156	660*400*245	972*480*245
Weight (kg)	34	50	48	94	145	50	98	148

Product Introduction :The product adopts a modular design with higher integration to save installation space. It uses high-performance lithium iron phosphate cathode material with excellent cell consistency. It supports one-key power on/off, front operation, and top wiring for easy installation, maintenance, and operation. It features diverse functions including overtemperature alarm and protection, overcharge/over-discharge protection, and short-circuit protection. With strong compatibility, it can seamlessly connect with main equipment such as UPS and photovoltaic power generation systems. It is equipped with various communication interfaces, including standard RS485 and CAN, enabling flexible remote system monitoring. As a high-energy,low-power-consumption lithium battery device, it delivers higher energy supply, lower energy consumption, and reduced environmental pollution. Comprehensive and multi-level battery protection strategies and fault isolation measures are adopted to ensure the safe operation of the system.
