Low-Voltage Lithium Outdoor Energy Storage Cabinet Modular C&I Battery ESS

ModelGSL-Link Ⅱ Series
StyleOutdoor Cabinet
CellREPT、EVE、etc
Cycle6000+ times
Life10 years
CertificateCE 、MSDS、UN38.3
Model / Specification25k+50kWh37.5k+80kWh50k+100kWh
Inverter Output
Rated Output Power (W)25,00037,50050,000
Maximum Peak Power (W)38,00057,00076,000
Inverter & Bypass Switching Time10ms (Typical)
Battery
Battery Capacity (kWh)5080100
Charge / Discharge Rate (C)0.50.50.5
Solar Charging (PV)
MPPT Quantity468
Maximum PV Array Power (W)6600*46600*66600*8
Maximum PV Input Current (A)22*422*622*8
Maximum Open Circuit Voltage (VDC)500*4500*6500*8
MPPT Operating Range (VDC)120~450 (Single Phase) / 200~650 (Three Phase)
Grid Input (AC)
Input Voltage Range (VAC)90~280 / 170~280
Frequency Range (Hz)50/60 ± 0.3
Protection & General Parameters
Protection LevelIP54
Dimensions (W*D*H) mm1240*635*19501240*1240*15301240*1240*2040
Weight (kg)540870998

Product Details

Product features:
  • Efficient integration, integrated solution: Integrating photovoltaics, energy storage, inverters, and power distribution, it is easy to install, operate, and maintain. The integrated design has low space occupation and is suitable for multiple scenarios such as household use and industrial and commercial use.
  • Intelligent optical storage, flexible scheduling: Supporting multiple operating modes, the light storage collaborative algorithm improves the proportion of spontaneous self use, has peak shaving and valley filling functions, and effectively saves electricity costs.
  • Safe, reliable, stable and durable: Adopting high safety battery cells and multi-level protection, combined with BMS intelligent management system, it has multiple protection mechanisms to ensure equipment safety.
  • Convenient operation and visual management: High definition touch screen displays core data, supports local and mobile APP remote dual channel control, standardized wiring reduces construction difficulty.
  • Multi adaptability and strong scalability: Multiple power capacities are available, compatible with grid/off grid switching, comes standard with multiple communication methods, and supports remote upgrades and fault diagnosis.
Product Introduction: This photovoltaic lithium battery integrated machine is a mobile clean energy power supply equipment that integrates photovoltaics, energy storage, inverters, and power distribution. It is flexible to deploy and does not require complex splicing, greatly simplifying the process Installation and operation process, integrated compact structure with high space utilization, can adapt to diverse scenarios such as household use, industry and commerce, temporary emergency, etc. The product is equipped with an intelligent light storage system, supporting photovoltaic priority and negative Multiple operating modes such as load priority and grid connection priority, combined with dedicated photovoltaic storage collaborative algorithms, maximize the proportion of self use and self use; Equipped with peak shaving and valley filling function, it can store electricity during low periods and discharge during high periods, effectively Reduce electricity costs.
