Turnkey 125kW Liquid-Cooled Commercial Battery Energy Storage Outdoor BESS

  • /
  • PRODUCTS
Liquid-Cooled ESS Cabinet
Liquid-Cooled ESS Cabinet

Turnkey 125kW Liquid-Cooled Commercial Battery Energy Storage Outdoor BESS

ModelGYL-PC261 Series
StyleLiquid-Cooled Outdoor Integrated Cabinet
CellREPT, EVE etc
Cycle6000+ times
Life10 years
CertificateCE , MSDS, UN38.3
Get a Quote
Advantages of energy storage factories

Professional Smart Power & Energy Solutions!

  JIANGSU GSO NEW ENERGY TECHNOLOGY CO., LTD is a national high-tech enterprise and a technology innovation enterprise dedicated to photovoltaic and energy storage industry with independent R&D capabilities. Relying on the profound technical accumulation of power electronics from its group company, the company deeply integrates digital intelligent technology with core energy storage technology.
  It professionally covers a full industrial chain of products including inverters, lithium battery PACK, residential energy storage, commercial & industrial energy storage, mobile energy storage, energy storage converters, photovoltaic-energy storage systems and smart microgrids, and has built a full-life-cycle photovoltaic & energy storage product matrix covering residential, commercial & industrial and special scenarios.
  Our products have passed a full range of ISO certifications, EU CE, UN38.3, MSDS, IEC, goods transportation condition appraisal and many other authoritative domestic and
Overseas customer case feedback
DC Battery ParamsProduct ModelCell TypeGYL-261
Cell TypeLFP 3.2V / 314Ah
Battery System Config1P260S
Battery Voltage Range728V ~ 923V
Battery Capacity261kWh
C/D Rate≤0.5C
AC Params (Grid-Tied)Rated Power125kW
Rated Grid Voltage230V/400V, -15%~+15%
Rated Grid Freq50/60Hz, ±5Hz
Power Factor-1 (leading) ~ 1 (lagging)
AC THDi<2% (of rated output power)
Connection Mode3P+PE three-phase three-wire / 3P+N+PE three-phase four-wire
AC Params (Off-Grid)Rated Output Voltage230V/400V
Rated Output Power125kW
Rated Output Freq50/60Hz
AC THDu<3% (linear load)
System ParamsAmbient Temp Range-30℃ ~ +55℃ (Derating above 45℃)
Ambient Humidity Range0~95%RH
Max Operating Altitude4000m (Derating above 2000m)
IP RatingIP54
Cooling TypeLiquid Cooling
WeightApprox. 2.7t
Dimensions (W×D×H, mm)1000×1340×2390 mm

Product Details

Next-Generation 125kW / 261kWh Liquid-Cooled BESS for Commercial & Industrial Applications

The GYL-261 integrates high-density LFP 314Ah batteries, bidirectional PCS, precision liquid cooling, and intelligent cloud EMS into a compact IP54 enclosure. Built for peak shaving, demand response, backup power, and smart microgrid integration.

Why Choose the GYL-261 Liquid-Cooled Cabinet?

  • Safe & Reliable: Built-in AI early warning system paired with 3D multi-layer fire safety (detection, prevention, active ventilation, and aerosol fire suppression).
  • Extended Battery Life: Advanced liquid thermal management keeps cell temperature difference ΔT ≤ 5°C, significantly reducing cell degradation in extreme climates.
  • High Efficiency & Flexibility: Maximum conversion efficiency ≥ 90% with standardized DC voltage (728V–923V) and reserved interfaces for fast site deployment.
  • Intelligent Cloud O&M: Real-time remote Web/APP management, automated AI dispatch strategy to optimize power tariffs, and one-click OTA firmware upgrades.

The GYL-261 Liquid-Cooled Outdoor Integrated Cabinet is a high-efficiency 125kW / 261kWh all-in-one battery energy storage system (BESS) engineered for commercial, industrial, and microgrid applications.

Key Highlights: • Advanced Liquid Cooling: Maintains battery cell temperature difference ΔT ≤ 5°C for extended LFP lifecycle. • Proactive 3D Fire Safety: Integrated AI early warning, smoke detection, active ventilation, and fire suppression. • High Conversion Efficiency: Maximum system efficiency ≥ 90% with low THDi (< 2%). • All-Weather IP54 Cabinet: Operating range -30°C to +55°C, high wind, sand-dust resistance, and up to 4000m altitude deployment. • Smart Cloud Operation: Real-time Web/App monitoring, AI dispatch algorithms, and remote OTA upgrades.
